Name: 2014-2021 Toyota Tundra | Double Cab | Reference 500
Brand: OEM Audio Plus
Price: 1699.0 USD
Availability: InStock

2014-2021 Toyota Tundra Double Cab | Reference 500

$1,699.00

Shipping calculated at checkout.

Quantity

Buil-In-Batches

Amplifier, Speakers, & Subwoofer

The Reference 500 is designed and tuned specifically for your '14-Present Toyota Tundra Double Cab. Guaranteed to deliver unmatched sound reproduction, seamless integration, and uncompromising reliability. What you can expect; unparalleled clarity, loudness, and ever-present bass without impeding vocals.

Included:
✔ 8″ Quad-Coil Subwoofer System
✔ Dedicated Subwoofer Amp (*Optional*)
✔ Multi-Channel 64-Bit DSP Power Amplifier
✔ Quick-Sync Wiring Harness
✔ Front 1″ Soft Dome Tweeter (Pair)
✔ Front 6″ x 9″ Carbon Fiber Woofer (Pair)
✔ Rear 6.5″ Carbon Fiber Woofer (Pair)

Fitment: 2014-2021 Toyota Tundra Double Cab

➜ Speakers
Superior dynamics, blending and low frequency response
Engineered for the perfect fit (drop-in installation)
Cutting edge performance w/ carbon fiber cone & neodymium magnet
➜ Subwoofer
All the emotional weight of your music
14-liter sealed fiberglass cabinet
Installs seamlessly using factory hardware locations
Non-invasive design preserves all usable space
➜ Amplification
Highly efficient Class HD Speaker Amplifier
Powers and remasters all speakers + subwoofer
Superior dynamics, volume, and impact
360 Watts RMS (Continuous / @ 2-ohms)
Subwoofer Amplifier (Optional)
Subwoofer gain control knob.
320 Watts RMS (Continuous / @ 4-ohms)
➜ 64-Bit Digital Signal Processing
Calibrated to deliver high-resolution audio upon plug in
You can expect seamless, full-range, detailed sound reproduction
Extremely powerful 64 bit processing power and sound optimization
295 MHz DSP Chip | Class HD Topology

MULTI-CHANNEL 64-BIT DSP POWER AMPLIFIER
360 Watts RMS (Continuous / @ 2-ohms)
Cirrus-Logic 64-Bit Digital Signal Processing
Real-time system diagnosis for trouble-free operation
Meets all OEM standards including AEC-Q100
TUNDRA DOUBLE-CAB SUBWOOFER SYSTEM
8″ Quad Voice-Coil Subwoofer
Genuine Carbon Fiber Cone Woofer
100W RMS (200 Peak)
Sensitivity 88.9dB (1 W,1M)
Frequency Response: 20 -1000 Hz
DEDICATED SUBWOOFER AMPLIFIER* (OPTIONAL)
Adds More Headroom + Low-Frequency Extension
250 Watts RMS
Class D (95% efficient)
Includes Gain Control Knob for precision adjustability
*Can be added in the future seamlessly
QUICK-SYNC WIRING HARNESS
Maintains all factory functionality
Constructed of genuine OEM connectors
Fuse Holder Assembly is element proof butt-connectors w/ built-in solder
< 4lbs / 1.8kg

➜ All OEM Audio Plus components meet OEM specifications and include 3 year/36,000 mile warranty whether installed by an Authorized Dealer or if you opt to Do It Yourself. Factory Warranty is not affected if installation is followed according to OEM Audio Plus installation guidelines.
