Included:
✔ 2 Low Profile Foot Rails
✔ 1 Slimline II Tray
✔ 1 Wind Deflector
✔ Installation Hardware
✔ Fitting Instructions
Fitment: 2007-2021 Toyota Tundra Crew Max
Please Note:
➜ Drilling is required for installation.
➜ Some side mount accessories are not suited for low profile foot rails such as Hi-Lift Jack Bracket and Recovery Device & Gear Holding Side Brackets.
Material Used:
Black Epoxy Powder - coated T6 aluminum
High Strength Steel
Dimensions:
Slimline II Tray: 1425mm(W)X1560mm(L)
Approximate Installed Weight: 32.6kg (71.87lbs)
➜ The t-slots on the tops and bottoms of the rack tray slats and edge profiles accommodate standard 8mm bolts.
➜ To determine the approximate height from your vehicle’s roof to the top of your Slimline II Roof Rack, add the height of the Slimline II Tray (50mm/2") to the height of the Foot or Grab-on Foot listed above.
➜ If your Slimline II Roof Rack kit uses Legs, add the height of the Slimline II Tray (50mm/2") to the height of the Legs to determine the height of the rack from your vehicle's rain gutters.
➜ If your Slimline II Roof Rack kit uses Foot Rails, add the height of the Slimline II Tray (50mm/2") to the height of the Foot Rails to determine the height of the rack from the crown (highest point) of the vehicles roof.
Shipping Dimensions:
Width: 450mm (18")
Length: 1840mm (72")
Height: 300mm (12")
Shipping Weight: 33.88kg (75lbs)
All Front Runner Racks are backed by a Limited Lifetime Warranty.
