Description
WORK SMARTER, NOT HARDER
LOAD IT UP AND GET TO WORK
Never crawl into your truck bed or van again.
Multi-position cargo stops.
Industrial-grade American steel and aluminum.
Tray uses resin coated marine-grade plywood.
ROLL IT OUT AND GET ROLLIN'
Ballsy ball bearings for buttery-smooth action.
Easily operated with one hand (& a donut).
Goes on top of Drawers for the ultimate setup.
Installation so quick and simple, monkeys can do it.
YOU WANT OPTIONS? WE GOT OPTIONS
1,000 lb, 1,500 lb, 2,200 lb payload options.
Choose 70% or 100% extension.
High Sides and additional tie downs available.
Beer and pretzels, Drawers and CargoGlide.
Please Note:
➜ Your payload is limited to 500lbs on the DECKED CargoGlide when mounted to a midsize Drawer System.
➜ Your truck has a ~1,000 lb payload. To not exceed your payload, be aware that your CargoGlide only has a 500lb payload when mounted on a midsize Drawer System.
➜ DRAWER SYSTEM SOLD SEPARATELY.
➜ In order to install CargoGlide on top of a new Drawer System you'll need our brackets.
➜ TAILGATE CLEARANCE: Some tailgates don't lay flat when open, which will cause binding when extending the CargoGlide tray. The highest point on your tailgate when open must be less than 3/4" above your truck bed floor to ensure compatibility. Before drilling into your bed, test the fit according to our install instructions.
➜ Compatible with DECKED Drawer System, Spray-In Bed Liners
➜ Not compatible with : Carbon Pro Bed, 5th Wheel/Gooseneck, Service Body, Bedrug / Drop-in Plastic Bed Liner, Stepside / Flareside
Installation Guide:
Features
➜ The Drawer System compatible CargoGlide comes with a 1,000 lbs payload (weight that can be loaded on top of the sliding tray).
CARGOGLIDE MATERIALS:
Powder coated USA steel frame
Industrial 0.75” Marine Plywood deck, Coated with a thermoplastic top sheet
Aluminum sidewalls
14 double roller bearings mid frame 3203zz
12 side thrust bearings mid frame 6201
2 Cam follower bearings bottom frame (tailgate end) 1.25" CYR
Specs
Size 5’1’’
Weight: 136 lb. | Payload: 1000 lb.
SYSTEM DIMENSIONS:
A (Width): 41.75 in. | B (Length): 56 in. | C (Height): 7 in.
TRAY DIMENSIONS:
Tray Width: 41 in. | Tray Length: 55 in. | Tray Height: 4 in.
Extension: 70%.
Size 6’2’’
Weight: 143 lb. | Payload: 1000 lb.
SYSTEM DIMENSIONS:
A (Width): 41.75 in. | B (Length): 68 in. | C (Height): 7 in.
TRAY DIMENSIONS:
Tray Width: 41 in. | Tray Length: 67 in. | Tray Height: 4 in.
Extension: 70%.
Warranty
DECKED LLC, (the “Manufacturer”) warrants the original purchaser only that DECKED Truck and Van Products including the Drawer System, Tool Box, CargoGlide, and Accessories (The “DECKED” Product) will be free from defects in material and workmanship from the date of purchase and continuing for the expected lifetime of the DECKED Product. Valid on products purchased on or after 8/1/2021.
More Info Here
